CONNECTION PLATES CC
Designed to connect the profiles of the horizontal frame of the raised floor in one plane
Diameter of holes for bolt connections M10.
Set of hardware for connection with profile ST 41-41:
■ Quick-clamping nut type SS-41 M10.
■ Bolt M10x30
■ Washer 10/125

TWO-DIMENSIONAL CORNERS ST 41-UD
CONNECTION PLATES CC
Designed to create spatial frame structures from profile ST 41-41 at an angle of 90°.
Suitable for mounting to walls, floors and ceilings.
Used in the construction of raised floor steps.
Diameter of holes for bolt connections M10.
Set of hardware for connection to profile ST 41-41:
■ Quick-clamping nut type SS-41 M10.
■ M10x30 bolt.
■ Washer 10/125.
